Asus ROG STRIX Z390-E GAMING User Manual

ROG STRIX Z390-E GAMING
3-19
Chapter 3
3.6.7 Onboard Devices Configuration
The items in this menu allow you to switch between PCIe Lanes and congure onboard
devices.
HD Audio
This item allows you to enable or disable the High Denition Audio.
Conguration options: [Disabled] [Enabled]
Intel LAN Controller
This item allows you to enable or disable the Intel LAN controller.
Conguration options: [Disabled] [Enabled]
LED lighting
When system is in working state
This item allows you to turn the RGB LED lighting on or off when the system is in the
working state.
Conguration options: [On] [Off]
When system is in sleep, hibernate or soft off states
This item allows you to turn the RGB LED lighting on or off when the system is in the
sleep, hibernate or soft off states.
Conguration options: [On] [Off]
M.2_1 Configuration
[Auto] Auto-detects the M.2 device mode. If a SATA device is detected,
SATA6G_2 will be disabled.
[SATA] Only supports M.2 SATA devices. Please note that SATA6G_2 port cannot
be used in this mode.
[PCIE] Only supports M.2 PCIE devices.
PCIEX16_3 Bandwidth
[X2 Mode] Run at X2 mode with SATA6G_56 enabled.
[X4 Mode] Run at X4 mode for higher performance with SATA6G_56 disabled.
3.6.6 PCH-FW Configuration
This item allows you to congure the rmware TPM.
SATA6G_1(Black) - SATA6G_6(Black)
SATA6G_1(Black) - SATA6G_6(Black)
This item allows you to enable or disable the selected SATA port.
Conguration options: [Disabled] [Enabled]
Hot Plug
These items appears only when the SATA Mode Selection is set to [AHCI] and allows
you to enable or disable SATA Hot Plug Support.
Conguration options: [Disabled] [Enabled]

Asus ROG STRIX Z390-E GAMING Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666, 2800, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3733, 3866, 4000, 4133, 4266 MHz
Component for	PC
Motherboard chipset	Intel Z390
Audio output channels	7.1 channels
Motherboard form factor	ATX
Motherboard chipset family	Intel
Windows operating systems supported	Windows 10
BIOS type	UEFI AMI
ACPI version	6.1
BIOS memory size	16 Mbit
Cables included	SATA
USB 2.0 connectors	2
Number of SATA II connectors	0
Number of SATA III connectors	6
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
PCI Express x1 (Gen 3.x) slots	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Intel® I219-V
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	5.0
RAID levels	0, 1, 5, 10
Graphics card	HD Graphics
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	2-Way SLI, 3-Way CrossFireX
Processor socket	LGA 1151 (Socket H4)
Compatible processor series	Intel Celeron, Intel Pentium

Weight and Dimensions

Depth	244 mm
Width	305 mm
