ROG STRIX Z390-F GAMING
3-3
Chapter 3
3.2.1 Advanced Mode
The Advanced Mode provides advanced options for experienced end-users to congure
the BIOS settings. The gure below shows an example of the Advanced Mode. Refer to the
following sections for the detailed congurations.
The default screen for entering the BIOS setup program can be changed. Refer to the
Setup Mode item in section Boot menu for details.
Menu items
General help
Menu bar
Language Qfan Control(F6) AI OC Guide(F11)
MyFavorite(F3) AURA ON/OFF(F4)
Search(F9)
Scroll bar
Pop-up Menu
Configuration fields
Last modified settings
Go back to EZ Mode
EZ Tuning Wizard
Hot Keys
Displays a quick overview of the
system status and prediction
Search on the FAQ

Asus ROG STRIX Z390-F GAMING Specifications

General

Chipset	Intel Z390
CPU Socket	LGA 1151
Form Factor	ATX
Memory Slots	4
Max Memory	64 GB
Memory Type	DDR4
PCIe x16 Slots	3
PCIe 3.0 x16 Slots	2
PCIe x1 Slots	3
M.2 Slots	2
SATA Ports	6
USB 3.1 Gen 1 (Back Panel)	4
USB 2.0 (Back Panel)	2
LAN	Intel I219-V Gigabit LAN
Audio	ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
RAID Support	0, 1, 5, 10
Multi-GPU Support	NVIDIA 2-Way SLI, AMD 3-Way CrossFireX
