Asus RS720-E7/RS12 - Front Panel Features; Rear Panel Features

Chapter 1: Product introduction1-4
1.3 Front panel features
1.4 Rear panel features
* The port is for ASUS ASMB6-iKVM controller card only.
PS/2 keyboard port
USB ports
LAN port 1
VGA port
6 Expansion slots
LAN port 2
Power cord
connector
PS/2 mouse port
Redundant power
supply
DM_LAN1 port*
LAN port 3 LAN port 4
1
2
USB ports Power button
Front panel
LEDs
Location
switch
Reset button
RS720-E7/RS12-E
HDD 9 (SAS/SATA) HDD 10 (SAS/SATA) HDD 11 (SAS/SATA) HDD 12 (SAS/SATA)
HDD 1 (SAS/SATA) HDD 2 (SAS/SATA) HDD 3 (SAS/SATA) HDD 4 (SAS/SATA)
HDD 5 (SAS/SATA) HDD 6 (SAS/SATA) HDD 7 (SAS/SATA) HDD 8 (SAS/SATA)
1
2
Power button
Front panel
LEDs
Location
switch
Reset button
HDD 1 (SAS/SATA) HDD 2 (SAS/SATA) HDD 3 (SAS/SATA) HDD 4 (SAS/SATA)
HDD 5 (SAS/SATA)
HDD 6 (SAS/SATA)
HDD 7 (SAS/SATA) HDD 8 (SAS/SATA)
HDD 9 (SATA) HDD 10 (SATA) HDD 11 (SATA) HDD 12 (SATA)
RS720-E7/RS12
USB ports
Power supply
dummy
