LAN LED
O: No power or no physical connection.
On: Has physical connection to a local area network (LAN).
3
WAN LED
O: No power or no physical connection.
On: Has physical connection to a wide area network (WAN).
4
5GHz LED
O: No 5GHz signal.
On: Wireless system is ready.
Flashing: Transmitting or receiving data via wireless connection.
5
2.4GHz LED
O: No 2.4GHz signal.
On: Wireless system is ready.
Flashing: Transmitting or receiving data via wireless connection.
6
Power LED
O: No power.
On: Device is ready.
Flashing slow: Rescue mode
Flashing quick: WPS is processing.
7
WAN (Internet) port
Connect a network cable into this port to establish WAN connection.
Yellow LED: 1000Mbps connection.
Green LED: 10Mbps/100Mbps connection.
Flashing: Transmitting or receiving data via wired connection.
8
Reset button
This button resets or restores the system to its factory default settings.
9
LAN 1 ~ 4 ports
Connect network cables into these ports to establish LAN connection.
Yellow LED: 1000Mbps connection.
Green LED: 10Mbps/100Mbps connection.
Flashing: Transmitting or receiving data via wired connection.
USB 3.0 ports
Insert USB 3.0 devices such as USB hard disks or USB ash drives into these ports.
11
Power (DC-In) port
Insert the bundled AC adapter into this port and connect your router to a power source.
Power Switch
Slide up to turn ON the device or slide down to turn it OFF.
13
WPS button
This button launches the WPS Wizard.
10
12
