ix
CPU
LGA1151 socket for 6th Generation Intel
®
Core™ i7/ i5/ i3/Pentium
®
/
Celeron
®
Processors
Supports 14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The support of these features depends on the CPU types.
**
Refer to www.asus.com for the complete CPU support list.
Chipset
Intel
®
Z170 Express Chipset
Memory
4 x DIMM, max. 64GB, DDR4 2400/2133 MHz, non-ECC, un-
buffered memory
Dual channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of
individual CPUs. Please refer to Memory QVL (Qualified Vendors List)
for details.
**
Refer to www.asus.com or this user guide for the complete Memory
QVL (Qualified Vendors List).
Expansion slots
2 x PCI Express 3.0/2.0 x16 slots (single at x16 or dual at x8/x8
mode)
1 x PCI Express 3.0/2.0 x16 slot* (max. at x4 mode, compatible with
PCIe x1, x2 and x4 devices)
3 x PCI Express 3.0/2.0 x1 slots
* The PCIe x16_3 slot shares bandwidth with SATA6G_56. The PCIe
x16_3 is default set at x2 mode.
VGA
Integrated Graphics Processor- Intel
®
HD Graphics support
Multi-VGA output support: DisplayPort/HDMI port
Supports DisplayPort 1.2* with max. resolution 4096 x 2160@24Hz
/ 3840 x 2160@60Hz
Supports HDMI 1.4b with max. resolution 4096 x 2160@24Hz /
2560 x 1600@60Hz
Supports Intel
®
InTru™ 3D/Quick Sync Video/Clear Video HD
Technology/Insider™
Maximum shared memory of 1024MB
* DP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor
daisy chain up to 3 displays
Multi-GPU support
Supports NVIDIA
®
2-Way/Quad-GPU SLI™ Technology (with 2 PCIex16
graphics card)
Supports AMD
®
3-Way/Quad-GPU CrossFireX™ Technology
LAN
Gigabit Intel LAN connection- 802.3az Energy Efcient Ethernet
(EEE) appliance
Intel
®
I219-V Gigabit LAN- Dual interconnect between the integrated
Media Access Controller (MAC) and physical layer (PHY)
Realtek
®
8111H Gigabit LAN controller
TUF LANGuard
ASUS Turbo LAN Utility
(continued on the next page)
SABERTOOTH Z170 MARK 1 specifications summary
