ASUS STRIX X99 GAMING
1-33
Chapter 1
16. Front panel audio connector (10-1 pin AAFP)
Thisconnectorisforachassis-mountedfrontpanelaudioI/Omodulethatsupports
eitherHDAudioorlegacyAC’97audiostandard.Connectoneendofthefrontpanel
audioI/Omodulecabletothisconnector.
• Werecommendthatyouconnectahigh-denitionfrontpanelaudiomoduletothis
connectortoavailofthemotherboard’shigh-denitionaudiocapability.
• Ifyouwanttoconnectahigh-denitionoranAC’97frontpanelaudiomoduletothis
connector,settheFrontPanelTypeitemintheBIOSsetupto[HD] or [AC97].
