Asus TS700-E6/RS8 - System Overview

ASUS TS700-E6/RS8 1-3
1.2 System overview
Items Items
1. Central processing unit (CPU) 6. MIO Audio card (optional)
2. CPU heatsink and fan 7. ASUS PIKE SAS RAID card (optional)
3. System memory 8. ASUS Server management board (optional)
4. Hard disk drives 9. Redundant power supply (optional)
5. HDD trays 10. Rackmount rail kit (optional)
1
2
10
10
4
3
5
8
7
6
9
