Chapter 1: Product introduction1-4
1.3 Front panel features
Optical drive
Power button
Reset button
Message LED
HDD access LED
Power LED
Security lock
LAN1 LED
LAN2 LED
4-bay HDD cage
4-bay HDD cage
Empty 5.25-inch
bays
USB 2.0 ports
Headphone output jack*
Microphone jack*
* The audio jacks function only with an optional MIO audio card.
