48
To set up 3G/4G internet access:
1. From the navigation panel, click General > USB application >
3G/4G.
2. In the Enable USB Modem eld, select Yes.
3. Set up the following:
• Location: Select your 3G/4G service providers location from
the dropdown list.
ISP: Select your Internet Service Provider (ISP) from the
dropdown list.
APN (Access Point Name) service (optional): Contact your
3G/4G service provider for detailed information.
Dial Number and PIN code: The 3G/4G providers access
number and PIN code for connection.
NOTE: PIN code may vary from dierent providers.
Username / Password: The username and password will be
provided by the 3G/4G network carrier.
USB Adapter: Choose your USB 3G / 4G adapter from the
dropdown list. If you are not sure of your USB adapters
model or the model is not listed in the options, select Auto.
4. Click Apply.
NOTE: The router will reboot for the settings to take eect.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus TUF-AX3000 and is the answer not in the manual?

Asus TUF-AX3000 Specifications

General IconGeneral
Wi-Fi StandardWi-Fi 6 (802.11ax)
Maximum Data Rate3000 Mbps
Frequency Bands2.4 GHz, 5 GHz
Antennas4 external antennas
MU-MIMOYes
BeamformingYes
OFDMAYes
RAM512 MB
Flash Memory256 MB
Ports1 x Gigabit WAN, 4 x Gigabit LAN
SecurityWPA3, WPA2, WPA
VPN SupportPPTP, L2TP, OpenVPN
AiProtectionAiProtection Pro
Gaming FeaturesGame Boost
