3-3
ASUS LCD Monitor VG32V Series
2.2 Detaching the arm/stand (for VESA wall
mount)
The detachable stand of this monitor is specially designed for VESA wall
mount.
To detach the arm/stand
1. Disconnect power and signal cables. Carefully put the monitor
facedown on its EPS packaging.
2. Remove the screws covers.
3. Remove the four (4) screws securing the arm to the rear of the
monitor.
4. Detach the stand (arm and base) from the monitor.
• The VESA wall mount kit ( 100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load 28.8 kg
(Screw size: M4 x 10 mm).
