Asus VG35VQ User Manual

1-5
ASUS LCD Monitor VG35V Series
• Activate Crosshair, Timer or FPS Counter or Display Alignment
function
• Move the ( ) button up/down to select and press ( ) to
confirm the function needed. Press to go off, and exit.
• Crosshair/Timer/FPS Counter is movable by pressing 5-way key.
GamePlus main menu GamePlus-Crosshair GamePlus-Timer
(Practice Mode)
5. Close Button
• Exit the OSD menu.
6. (5-way) Button:
• Turns on the OSD menu. Enacts the selected OSD menu item.
• Increases/Decreases values or moves your selection up/down/left/right

Asus VG35VQ Specifications

General

Panel Size	35”W (88.9cm)
Max. Resolution	3440x1440@100Hz
Brightness (Typ.)	300cd/m2
Intrinsic Contrast Ratio (Typ.)	2500:1
Viewing Angle (CR=10)	178°(V) /178°(H)
Display Colors	16.7 M
Response Time	4ms (Gray to Gray) 1ms MPRT
Earphone Output	Yes
Sound from HDMI	Yes
HDMI input	Yes
DisplayPort input	Yes
Power ON Consumption(Max.)	< 45 W* (Measuring a screen brightness of 200 nits without audio/ USB/ Card reader connection)
Power saving mode	< 0.5W
Power off mode	< 0.5W
Voltage Rating	AC 100~240V(Built-in)
Chassis Colors	Black
Tilt	-5° ~ +20°
Temperature (operating)	0°C ~ 40°C

Weight and Dimensions

Phys. Dimension (WxHxD)	834.6 x 561.1 x 231.6 mm
Phys. Dimension without stand (WxHxD)	834.6 x 381.4 x 122.9 mm
Box Dimension (WxHxD)	930 x 659 x 282 mm
Net Weight (Esti.)	12 kg
Gross Weight (Esti.)	17.2 kg
