Asus VG35VQ User Manual

3-1
ASUS LCD Monitor VG35V Series
3.1 OSD (On-Screen Display) menu
3.1.1 Howtorecongure
MOBA Mode
User Mode
GameVisual
Scenery Mode
RTS/RPG Mode
FPS Mode
Cinema Mode
Racing Mode
Racing Mode DisplayPort 1920x1080@60Hz
ASUS TUF Gaming VG35V HDR OFF
sRGB Mode
1. Press Central of 5-way to activate the OSD menu.
2. Press the  and  buttons to toggle between options in the
Menu. As you move from one icon to another, the option name is
highlighted.
3. To select the highlighted item on the menu press the Center key.
4. Press the  and  buttons to select the desired parameter.
5. Press the Center key to enter the slide bar and then use the  or
 buttons, according to the indicators on the menu, to make your
changes.
6. Press the ◄/► to move left / right menu.

Asus VG35VQ Specifications

General

Panel Size	35”W (88.9cm)
Max. Resolution	3440x1440@100Hz
Brightness (Typ.)	300cd/m2
Intrinsic Contrast Ratio (Typ.)	2500:1
Viewing Angle (CR=10)	178°(V) /178°(H)
Display Colors	16.7 M
Response Time	4ms (Gray to Gray) 1ms MPRT
Earphone Output	Yes
Sound from HDMI	Yes
HDMI input	Yes
DisplayPort input	Yes
Power ON Consumption(Max.)	< 45 W* (Measuring a screen brightness of 200 nits without audio/ USB/ Card reader connection)
Power saving mode	< 0.5W
Power off mode	< 0.5W
Voltage Rating	AC 100~240V(Built-in)
Chassis Colors	Black
Tilt	-5° ~ +20°
Temperature (operating)	0°C ~ 40°C

Weight and Dimensions

Phys. Dimension (WxHxD)	834.6 x 561.1 x 231.6 mm
Phys. Dimension without stand (WxHxD)	834.6 x 381.4 x 122.9 mm
Box Dimension (WxHxD)	930 x 659 x 282 mm
Net Weight (Esti.)	12 kg
Gross Weight (Esti.)	17.2 kg
