Asus VivoBook 15 X540UA User Manual

20 Notebook PC E-Manual
Left Side
Power (DC) input port
Insert the bundled power adapter into this port to charge the
battery pack and supply power to your Notebook PC.
WARNING! The adapter may become warm to hot while in use.
Do not cover the adapter and keep it away from your body while
it is connected to a power source.
IMPORTANT! Use only the bundled power adapter to charge the
battery pack and supply power to your Notebook PC.
MicroSD card slot
This built-in memory card reader slot supports microSD card
formats.

Asus VivoBook 15 X540UA Specifications

General

Operating System	Windows 10 Home
Weight	1.9 kg
Processor	Intel Core i3-6006U
RAM	8GB DDR4
Storage	1TB HDD
Display	15.6-inch Full HD (1920 x 1080)
Graphics	Intel HD Graphics 520
Battery	33WHrs, 3S1P, 3-cell Li-ion
Dimensions	381 x 251 x 27.2 mm (W x D x H)
Ports	1 x USB 3.0, 2 x USB 2.0, 1 x HDMI, 1 x VGA, 1 x Audio combo jack, 1 x RJ45 LAN
Connectivity	Bluetooth V4.0
Color	Silver Gradient
