Asus X99-DELUXE Series User Manual

3-4
Chapter 3: BIOS setup
Chapter 3
3.2.2 Advanced Mode
The Advanced Mode provides advanced options for experienced end-users to congure
the BIOS settings. The gure below shows an example of the Advanced Mode. Refer to the
following sections for the detailed congurations.
To switch from EZ Mode to Advanced Mode, click Advanced Mode or press F7 hotkey.
Configuration fields
Menu bar
Item descriptionSub-menu item
Menu items
Scroll bar
Last modified settings
Language
EZ Tuning Wizard
MyFavorite
Quick Note
Hot Keys
Goes back to EZ Mode
Displays the CPU/motherboard temperature,
CPU and memory voltage output
Q-Fan control

Asus X99-DELUXE Series Specifications

General

Chipset	Intel X99
CPU Socket	LGA 2011-v3
Memory Support	DDR4
Memory Slots	8
Maximum Memory	64GB
SATA 6Gb/s	8
SATA Express	2
Audio	Realtek ALC1150 8-Channel High Definition Audio CODEC
RAID Support	0, 1, 5, 10
Form Factor	ATX
Expansion Slots	4 x PCIe 3.0/2.0 x16 (x16 or dual x16/x16 or x16/x8/x8 or quad x8), 1 x PCIe 2.0 x4, 1 x PCIe 2.0 x1
M.2	1 x M.2 Socket 3, with M Key, type 2242/2260/2280/22110 storage devices support
USB 2.0 Ports	6
USB 3.1 Ports	2
LAN	Intel I218V
Multi-GPU Support	AMD Quad-GPU CrossFireX Support
USB 3.0 Ports	8 (4 at back panel, 4 at mid-board)
