14 ASUS Xonar DG
5.3 Connecting Analog Speaker Systems
5.3.1 Connecting Analog Power Amplier
1
2
3
No Item Description
1 Front Out
Connects to the “left front” and “right front” input ports of the
2 Side Surround Out
Connects to the “left surround” and “right surround” input
3 Center/Subwoofer
Connects to the “Center” and “subwoofer” input ports of the
To Next Page
