17ASUS Xonar DG
5.3.4 Connecting 5.1 Channel Speakers
No Item Description
1 Front Out
Connects to the Front input port of the 5.1 speakers with the
mini-jack cable.
2 Side Surround Out
Connects to the Surround input port of the 5.1 speakers with
the mini-jack cable.
3 Center/Subwoofer
Connects to the Center/Subwoofer input port of the 5.1
speakers with the mini-jack cable.
5.1 Speakers
1
2
3
