No Item Description
1 Display Area
This display area shows the 10-band signal meter, volume
level, and the status of the Dolby/DTS technologies, EQ, and
DSP modes.
Note: This area just displays information, but is not used to
alter settings.
2 Menu Open/Close
Clicking this button will move the display area and reveal
display area back down.
3 Master Volume
This rotary knob controls the master playback volume. Drag
the small circle inside it to change the volume level.
4 SVN Button
feature for constant volume from all playback sources. It will
display a blue light when enabled.
5 Mute Button
light when playback is muted.
6 DSP Mode
These 2 buttons give access to quick gaming surround
sound effect (GX2.5) and effect-free (Hi-Fi) modes.
7 Setting Menu Panel
This panel gives access to setting tabs, including Main
Settings, Mixer/volume, Effects, Karaoke, FlexBass, and
VocalFX.
8 Information icon
Clicking this icon will pop up driver’s Information window.
