Asus Z170-E - USB Type C Power Switch [Auto]; Intel LAN Controller [Enabled]; Intel PXE OPROM [Disabled]; Serial Port Configuration

ASUS Z170-E Series
2-43
USB Type C Power Switch [Auto]
[Auto] The system will automatically detect your USB Type C devices and provide
suitable power if needed.
[Enabled] The USB Type C port will always provide power to your devices.
Intel LAN Controller [Enabled]
This item allows you to enable or disable the Intel LAN1/2 controllers.
Conguration options: [Disabled] [Enabled]
The following item appears only when you set the Intel LAN Controller to [Enabled].
Intel PXE OPROM [Disabled]
This item allows you to enable or disable the PXE OptionRom of the Intel
®
LAN
controller.
Conguration options: [Enabled] [Disabled]
Serial Port Configuration
The items in this menu allows you to set the parameters of the serial port.
This items in this menu works only if a serial port connector is installed on the motherboard.
Serial Port [On]
This item allows you to enable/disable the serial port.
Conguration options: [On] [Off]
Change Settings [IO=3F8h; IRQ=4]
This item allows you to select an optimal setting for Super IO device.
Conguration options: [IO=3F8h; IRQ=4] [IO=2F8h; IRQ=3] [IO=3E8h; IRQ=4]
[IO=2E8h; IRQ=3]
