ASUS Z170-E Series
2-49
The following four items appear only when you set Chassis Fan 1-2 Prole to [Manual].
Chassis Fan 1-2 Upper Temperature [70]
Use the <+> or <-> keys to adjust the upper limit of the Chassis Fan 1-2
temperature. The values range from 20 to 75.
Chassis Fan 1-2 Max. Duty Cycle (%) [100]
Use the <+> or <-> keys to adjust the maximum Chassis Fan 1-2 duty
cycle. The values range from 20% to 100%. When the CPU temperature
reaches the upper limit, the Chassis Fan 1-2 will operate at the maximum
duty cycle.
Chassis Fan 1-2 Middle Temperature [45]
Use the <+> or <-> keys to adjust the middle limit of the Chassis Fan 1-2
temperature. The values range from 20 to 75.
Chassis Fan 1-2 Middle. Duty Cycle (%) [60]
Use the <+> or <-> keys to adjust the maximum Chassis Fan 1-2 duty
cycle. The values range from 20% to 100%. When the CPU temperature
reaches the upper limit, the Chassis Fan 1-2 will operate at the maximum
duty cycle.
Chassis Fan 1-2 Lower Temperature [40]
Use the <+> or <-> keys to adjust the lower limit of the Chassis Fan 1-2
temperature. The values range from 20 to 75. The Chassis Fan 1-2 will
operate at the minimum duty cycle when the temperature is lower than the
limit.
Chassis Fan 1-2 Min. Duty Cycle(%) [60]
Use the <+> or <-> keys to adjust the minimum Chassis Fan 1-2 fan duty
cycle. The values range from 0% to 100%. When the CPU temperature is
under the limit, the Chassis Fan 1-2 fan will operate at the minimum duty
cycle.
ASUS FAN EXTENSION CARD is required to configure these items
Extension Fan 1-3 Q-Fan Control [DC Mode]
[Disabled] Disable the Extension Fan Q-Fan control feature.
[DC mode] Enable the Extension Fan Q-Fan control in DC mode for 3-pin chassis
fan.
[PWM mode] Enable the Extension Fan Q-Fan control in PWM mode for 4-pin
chassis fan.
Extension Fan 1-3 Q-Fan Source [CPU]
The assignment fan will be controlled according to the selected temperature source.
Conguration options: [CPU] [MotherBoard] [VRM] [PCH] [EXT_Sensor1] [EXT_
Sensor2] [EXT_Sensor3]
For EXT_Sensor1-3, connect a Thermistor cable to the EXT_TS1-3 header then place the
other end to the component to get the temperature.
Extension Fan 1-3 Fan Speed Low Limit [200 RPM]
This item allows you to disable or set the chassis fan warning speed.
Conguration options: [Ignore] [200 RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM]
