Asycube 380 & 530
Operating Manual
000.101.151
Version: B
41/50
Step 3
Step 4
Carefully disconnect the
connectors from the electronics
Remove the old backlight
assembly (D)
Replace the complete backlight
assembly or only a backlight
board by unscrewing the 8
screws (E) (it may be necessary
to use a tool to detach the
backlight print)
Use a torx key size 10
(D)
(E)
530
380
