ATA NeoSlider NES-800 User Manual

Name: ATA NeoSlider NES-800
Brand: ATA
Rating: 4 (1 reviews)

28 pages

To Next Page

NeoSlider

NES-500 & NES-800 Sliding Gate Openers

Ne Slider

™

Doc # 160065_03

Part # 13448

Released 17/03/17

Default Chapter2
- Table of Contents2
1 Important Safety Instructions3
2 Control Board Layout4
3 Set up Requirements5
- Kit Contents5
- Choosing Your Set up5
- Initial Checking5
4 Drive Unit Installation6
- Mounting the Drive Unit6
- Installing Antenna6
5 Rack & Limit Actuator Installation7
- Mounting Rack to Gate7
- Fixing Limit Actuator to Rack7
6 Programming the Neoslider8
- Common Programs8
- Powering up the Neoslider8
7 Safety Beams8
- Installation of Safety Beams to the Neoslider8
- Safety Beam Failure Emergency Close (SBFEC)8
8 Setting Limits9
- Setting Travel Limits9
- Setting the Left/Right Installation Side Settings9
- Setting Close Travel Limit9
- Setting Open Travel Limit9
- Automatic Limit Adjustment and Load Profile9
- Pedestrian Access Position9
- Errors During Setting of Travel Limit9
- Recalculate Force Margins9
9 Safety Obstruction Force Test10
- Testing Close Cycle10
- Testing Open Cycle10
- Force Pressure for Close and Open Cycle10
- Reprofiling Travel10
10 Coding Transmitter11
- Coding Transmitter Button11
- Selecting Function of the Button11
- Returning to Main Screen11
- Selecting the Function to be Coded11
11 Emergency Release12
- Your Gate CAN NOT be Used by the Opener When12
- Your Gate CAN be Used When12
- To Disengage the Opener12
- To Re-Engage the Opener12
12 Setting Pedestrian Position12
- Pedestrian Position Set12
- Error Displays12
13 Auto-Close Mode13
- Setting up Standard Auto-Close13
- Safety Beam Triggered Auto Close13
- Pedestrian Auto-Close13
- Auto-Close after Obstruction13
14 Accessories Installation14
- Fitting Solenoid or Magnetic Locks14
- Fitting Courtesy Lights14
15 Battery Replacement15
16 Battery Disposal15
17 Specifications16
18 Troubleshooting17
19 Appendix18
- A - Console Menu Structure18
- B - Viewing & Editing Parameters21
- C - Control Board Adjustments22
- D- Diagnostic Tools23
- E - Memory Tools24
- F- Transmitter Editing25
- G- Transmitter Managment26
20 Warranty and Exclusion of Liability27
