EN 15
INSTALLATION
Electrical connection
The appliance has been manufactured as a class I. The cable must
be connected to an earthed socket!
Make sure the supply voltage ratings correspond with those stated on
the appliance data plate. The connection to the mains is carried out as
follows:
BROWN = phase L
BLUE = phase N
YELLOW/GREEN = earth
This extractor hood has been provided with a power plug. When
installing the hood, make sure that this plug remains accessible. We
recommend installing the wall socket out of view, behind the chimney
cover.
Attention:
If you want to make a fixed connection, ensure that a multi-pole switch
with a distance between contacts of 3 mm is installed in the supply
cable.
