Atari PONG 4P User Manual

PONG 4P D&B Manual
11/18/2019
34
Coin Lock
J36
1.P1 Ticket Owed
Light
P1 Tickets
/Insert
Coin/Swipe
Card Signal
J38
1.P2 Ticket
Owed Light
P2 Tickets /Insert
Coin/Swipe Card
Signal
2.P1 Insert
Coin/Swipe Card
2.P2 Insert
Coin/Swipe Card
3.12V
3.12V
4.GND
4.GND
5.P1 Tickets Driver
5.P2 Ticket
Driver
6.P1 Tickets
Feedback
6.P2 Ticket
Feedback
7.12V
7.12V
8.GND
8.GND
J37
1.P3 Coin Counter
P3 Counter
Assembly/Ticke
ts /Insert
Coin/Swipe
Card Signal
J39
1.P4 Coin
Counter
P4 Counter
Assembly/Tickets
/Insert
Coin/Swipe Card
Signal
2.P3 Ticket
Counter
2.P4 Ticket
Counter
3.P3 Tickets Driver
3.P4 Ticket
Driver
4.P3 Ticket Owed
Light
4.P4 Ticket
Owed Light
5.GND
5.GND
6.P3 Insert
Coin/Swipe Card
6.-
7.P3 Test Button
7.-
8.-
8.-
9.P3 Tickets
Feedback
9.-
10.12V
10.12V
BUTTON-J2
1.GND
2.P4 Insert
Coin/Swipe Card
3.P4 Test Button
4.-
5.P4 Tickets
Feedback
6.-
