Atari PONG 4P User Manual

PONG 4P D&B Manual
11/18/2019
50
Step 5 Utilize Socket wrench to loosen 8 nuts on the under plate and 2 nuts on the inner
plate. It is the same operation on both Red Player & Blue Player positions.
Step 6 Unscrew the Cupholder metal plate, lift it up by hand.
Unplug the connectors to the Lifting motor, and take the Lifting motor assembly out.
Connectors
Lifting motor assembly
Cupholder
metal plate
Door
plate
Inner plate: Here
are 2 nuts
Under plate: Here
are 8 nuts
