Appendix
59
Specifications
AP206
Function AP206
System Specification
Rated Power 60W per Channel, 120W at Bridge Mode
Distortion THD+N: <0.1%, 1kHz, 3dB before clipping
Frequency Response 50–20k Hz, +/-3dB @4Ω, 1W
Sensitivity Balanced: +4dBu
Unbalanced: -10dBV
(0dBu=0.775Vrms, 0dBV=1Vrms)
Amplifier Type Class D
Audio Inputs
Interfaces 2 × 3-pin 3.5mm Euroblock (Bal/Unbal Line In)
Impedance Balanced: 20kΩ / Unbalanced: 10kΩ
Detect Threshold -50dBu
Audio Outputs
Interfaces Line Output: 1 × 5-pin 3.5mm Euroblock
Speaker Output: 1 × 2-pin 5.08mm Euroblock
Impedance Lo-Z: 4Ω / Hi-Z: 70V (40Ω), 100V (80Ω)
Line Output: 600Ω
Audio Effects Built-In DSP
Protection Output Shortcut
AMP Output over/under voltage
High Frequency Overload
Thermal Protect
Communication
RS-232 Connector: 3-pin, 3.5mm, Terminal Block
Baud rate and protocol:
Baud Rate: 19200, Data Bits: 8, Stop Bits:1, Parity: No,
Flow Control: No
Power
Power Consumption 100–240V~, 50/60Hz, 2A with PFC
Compliance
Certification FCC, CE, UKCA
