ECO 6 – User and installation manual
Release 5.1 7
Each active relay output is indicated by a red LED.
PRB > probe inputs
- Regular status: the LED lights up every 3 seconds
- Fail status: LED is on
Green and yellow leds indicate the presence of +12V e +3V power supply
For each CANBUS port, the reception and transmission status is indicated by a pair of LEDs.
