SL1 DATA LOGGER User Manual Rev. AD
sales.get@athena.euwww.getdata.it
ENGLISH
11.1 LYNXLOG: NAVIGATION BAR
Press to open the LynXLog SYSTEM page
Press to open the LynXLog MONITOR page
Press to open the LynXLog LOG CONFIG page
Press to open the LynXLog DATA page
Press to open the LynXLog HOME page
Press to open the LynXLog TRACK page
Press to open the LynXLog SETUP page
11.2 LYNXLOG: MAIN FUNCTIONS
LYNXLOG FUNCTION BUTTONS
BUTTON FUNCTION
DATA
Opens the acquisition management page, here the acquired data can
be downloaded, deleted and the destination folder can be set.
LOG CONFIG
Opens the acquisition configuration page where it is possible to change
the properties of the channels, log triggers, etc.
MONITOR
Opens the page that displays the channels in real-time, here the data
channel can be calibrated and viewed in real time.
SYSTEM
Opens the SL1 Data Logger hardware page, here it is possible to change
the various hardware settings and read device information.
TRACK
Opens the track creation page, where personal tracks can be created,
loaded and edited.
LYNXLOG SETUP
Opens the system configuration page where it is possible to change
the predefined software folders and the size of the character used on
the interface.
