SL1 DATA LOGGER User Manual Rev. AD
sales.get@athena.euwww.getdata.it
ENGLISH
12.5.4 CHANGING THE SETUP
INFO
All the information used to identify the Run,
vehicle, pilot, etc...
TRIGGERS They define acquisition start and stop
AN/FRQ
Configurations of the physical input channels,
ordered by function:
ANALOG (AN1,AN2,AN3 – EXP connector)
DIGITAL (IC1 on the MAIN connector)
CAN PORT GET CAN Bus port 1 (on the MAIN connector)
CAN PORT AUX CAN Bus port EXP (on the EXP connector)
GPS
GPS channels (latitude, longitude, number of
received satellites, GPS speed, etc.)
IMU Accelerometers, gyroscopes
See the structure of the setup options:
• By Pressing one of the options opens the relative table, edit the desired parameters (see
Annex 1).
