SL1 DATA LOGGER User Manual Rev. AD
sales.get@athena.euwww.getdata.it
ENGLISH
12.6.5 CALIBRATING A SUSPENSION CHANNEL ON THE
CHANNEL MONITOR LIST
• If the data channel you want to calibrate is a suspension sensor, a zero position must be set:
1) Add the channel to the Channel Monitor list (see
chapter 12.6.1)
2) Set the type of channel as suspension and select the length of the sensor stroke (see
6.4)
3) Make sure that the suspension is in the correct zero position
4) View the channel in real time (see
chapter 12.6.2)
5) Follow the instructions below to set the zero position:
• Press the Set 0 button to set the zero position, the value of the channel in mm will become
zero.
• Send the new setup to the SL1 Data Logger, pressing Set. Conf > in the actions column.
ATTENTION:
THE SET 0 FUNCTION IS ONLY AVAILABLE FOR SUSPENSION TYPE CHANNELS
