SL1 DATA LOGGER User Manual Rev. AD
sales.get@athena.euwww.getdata.it
ENGLISH
3 SETTING THE TRIGGERS
The TRIGGERS panel can be opened by pressing TRIGGERS once in the Config Channel Tree
column.
Acquisition start and stop is set to manual by default: press TRIGGERS and select the desired
channel from the drop-down menu.
NOTE: the list of channels varies based on the available configured channels
If the channel selected for starting acquisition is not Manual, the table will be completed with all
the options necessary for configuring automatic acquisition:
Configure as necessary and save the setup to a file or send it to the SL1 Data Logger when fini-
shed (see
chapters 12.5.3 and 12.5.5)
