SL1 DATA LOGGER User Manual Rev. AD
sales.get@athena.euwww.getdata.it
ENGLISH
5 CAN PORT GET AND CAN PORT EXP PANELS
The CAN Port GET or CAN Port EXP panels can be opened by pressing Config Channel Tree CAN
Port GET or CAN Port EXP.
These panels can be used to configure the properties of the data buses and the related channels.
• To add a new channel, press Add Channel in the Config Channel Tree column
Here it is possible to set the following properties of a CAN port :
• Bus Speed: this parameter makes it possible to set the bit-rate of the CAN BUS to one of the
possible values.
• Byte Order: this parameter makes it possible to set the format of the CAN BUS data to one of
the following:
Intel: Little Endian byte order
Motorola: Big Endian byte order
5.1 ADDING A NEW CAN CHANNEL
