SL1 DATA LOGGER User Manual Rev. AD
sales.get@athena.euwww.getdata.it
ENGLISH
6 CALIBRATING A CHANNEL
6.1 NONE CALIBRATION
To obtain an optimal representation of the acquired data, data must be calibrated.
Calibration is possible using the Channel Calibration page.
There are 4 types of calibration:
• None, the input data will not be calibrated and will be acquired as is (raw format)
• Linear, the input data will be calibrated linearly using a gain and offset
• Polyline, the input data will be calibrated using a multipoint calibration
• Suspension, use this type of calibration for suspension sensors
• If the None calibration option is used, the input data will not be calibrated and will be
acquired as is (raw format)
• An example of None calibration is shown below:
To change the type of calibration, press the Calibration Type drop-down menu and select None
