SL1 DATA LOGGER User Manual Rev. AD
sales.get@athena.euwww.getdata.it
ENGLISH
6.2 LINEAR CALIBRATION
• With the Linear calibration, a gain and an offset to be applied to the channel must be set:
• Press the gain field to enter the desired gain value
• Press the offset field to enter the desired offset value
ATTENTION: THE NEW CONFIGURATION IS NOT YET SAVED, SAVE IT TO A
FILE OR SEND IT TO THE SL1 DATA LOGGER SEE
CHAPTERS 12.5.3 AND 12.5.5
TO SEND THE NEW CALIBRATION TO THE SL1 DATA LOGGER:
PRESS THE BUTTON TO EXIT THE CHANNEL CALIBRATION PAGE, THEN
PRESS THE SET. CONF BUTTON >
To Next Page
