In your parking space, choose a spot on the wall close
to the socket.
Step 1: Install the wall mount at a height of 1.2m from
the ground. Ensure that there's a socket close to the wall
mount.
Step 2: Mark 2 holes vertically on the wall, using holes given
on Wall mount for mounting under the snap cover.
Step 3: Drill holes with an M6 drill and install the wall anchors.
Step 4: Align the wall mount to the holes and fasten with
the 2 mounting screws. Once done, close the screw cover.
Step 5: Attach the Duo to the wall mount, plug it in and
switch it ON.
Step 6: Now you can charge your vehicle where you park.
And when not charging, you can hang the charging handle
in the dock.
Step 7: Use the key given in the pack to unlock the Duo
from the wall mount.
→ Ensure the socket you will be using to plug your charger
is indoors, not exposed to water and rated for 6A.
→ Make sure the voltage dierence between Neutral and
Earth is below 25V.
4
Installation
Get your electrician to check the following:
