www.atkinsonelectronics.com Circuit Board Division
800.261.3602 Revised 05/19
Specifications for SEDM6-40
Size & Weight: 2.75 x 4.5 x .75 inches, 5 ounces
Mounting: Single - gang electric box or surface mount with cutout
Power: 12VDC from PVCM40D-MPT
Current Draw: 15 mA normal mode
25 mA with back light on
Connection: RJ-45 jack to T568A or T568B network Cat-5 patch cable
Control: Single select/ reset button
Display: 3 digit LCD to 999 or 99.9 with decimal
0.35 inch character height
Battery Percent
Display: 12.8V = 100%, 12.1V = 50%, 11.5V = 0%, 12V system
Battery Voltage: Displays 0 to 25VDC
Low Battery
Voltage: Detects @ 11.8V
Solar Voltage: Displays 0 to 25VDC
Current Display: 0 to 25 solar charge Amps
Below .3 Amps the display will indicate “chr”
if the controller is charging
Amp Hours: Displays 0 TO 999 accumulated
Charging Status: LED OFF: Not charging, display indicates “n_c”
Green LED: Float charge, display indicates “Fch”
Red LED: Bulk/ absorption charge “bch/Ach”
Manual Boost: Available only during float charging stage. Press and hold
Select button while in charging status location will force
PVCM40D-MPT into bulk charge mode
Temperature: 0 to 50°C
18
