P-2000 7.1 Channel Preamp/Processor/Tuner
Specications
Preamplier Analog Section
Input Impedance 26KΩ
Output Impedance (Main-RCA) <600Ω
Rated Input 2.0Vrms
Maximum Input 3.0Vrms
Rated Output (100kΩ load) 1.5Vrms
Minimum Load 5kΩ
Maximum Output 6.3Vrms
Volume Range
Main -80dB to +10.0 dB (1dB resolution)
Zone -80dB to +10.0 dB (1dB resolution)
Bass Management
High-Pass Slope Crossover Frequency
(Small Speaker Setting) (Adjustable 40/60/80/100/120/150Hz)
12 dB/octave (2nd order)
Low-Pass Slope (Subwoofer) 24 dB/octave (4th order), 40-150Hz as above
Tone Control
Bass Center Frequency/Range 30Hz / ± 6dB
Treble Center Frequency/Range 10KHz / ± 6db
Channel Separation (at 1kHz) 82dB
Crosstalk Between Inputs (at 1kHz) 86dB
Preamplier Digital Section
Frequency Response
Direct Inputs 10 Hz to 20 kHz +0 / -0.2 dB
Analog-DSP Inputs 10 Hz to 20 kHz +0 / -0.5 dB
Digital Inputs 10 Hz to 20 kHz +0 / -0.4 dB
THD+N (at Rated Input & Output)
6-Channel Direct Inputs 0.0035% (80 kHz BW)
Analog-Direct Inputs 0.0035% (AES17 lter)
Analog-DSP Inputs 0.005% (AES17 lter)
Digital Inputs 0.006% (80 kHz BW)
IMD (CCIF) @ 15 kHz & 16 kHz
6-Channel S/E Inputs 0.003%
All Other Analog Inputs 0.002%
Digital Inputs 0.005%
S/N Ratio (ref. 2.0Vrms A-weighted)
All Direct Inputs 102dB
Analog-DSP Inputs 99dB
Digital Inputs 101 dB
Zone 2 Section
Frequency Response and Bandwidth
THD+N (at Rated Input & Output) 0.01% (80kHz BW)
IMD (CCIF at 15kHz & 1 kHz) 0.01%
S/N Ratio (ref. 2.0Vrms A-weighted) 97dB
FM Tuner Section
Sensitivity
IHF 10dBµ typ.
50dB S/N 13dBµ typ.
S/N Ratio
Mono 75dB typ.
Stereo 69dB typ.
Distortion
Mono 0.2% typ.
Stereo 0.3% typ.
Stereo Separation 40dB typ.
Adjacent Channel Selectivity 70dB ± 400kHz
Frequency Response 20 Hz to 15 kHz ± 1dB
AM Tuner Section
Sensitivity (20dB S/N) 200uV
S/N 50dB
Distortion 0.7%
One Signal Selectivity (± 10kHz) 20 dB
Video Section
Bandwidth
Composite & S-Video 6 MHz –3dB
Component Green 50MHz -3dB
Component Red 50MHz -3dB
Component Blue 50MHz -3dB
All video inputs and outputs are 75 ohms, 1.5 Vp-p. Component inputs and outputs work with
any Standard requiring ultra-wide bandwidth including Component-RGB, HDTV, line doublers,
quadruplers, and scalers.
Digital Audio
All digital audio inputs and outputs are to S/PDIF electrical (75 ohms, 0.5 Vp-p),
S/PDIF optical (Toslink), or AES / EBU (110 ohms, 5 Vp-p) standards as appropriate.
Processor Crystal CS49326
Audio Converters
Digital Audio Inputs CS8415A Digital Audio Interface up to 96kHz
Analog to Digital CS5360 up to 24-bit/48kHz
Digital to Analog CS4396 up to 24-bit/192kHz
General
Supply Voltage 105-130V, 60Hz only
Power Consumption 45W
Fuse Rating 1.0A slow-blow 5x20 mm, 2.0A slow-blow 5x20mm
Dimensions
Width 17.12 inches / 435 mm
Height 4.6 inches / 117 mm
Depth 14.76 inches / 375 mm
Weight 17.6 lbs. / 8 kg
Trigger Outputs 1, 2(Zone) Sequential Delay 50 mA @ 12 VDC
