Atlantic Compact 100 L - Compatible Accessories

28
InstallationManual
28
2.Compatibleaccessories
Dielectric fting
Universal pedestal for vertical wall-mounted models
• Idealifnoload-bearingwall.
• Quickerassemblytime.
• Easieraccesstoequipment.
• Specialpassageforthesafetyunit.
• New,morestablemodel.
• Equippedwithpadstoavoidpunchingtheoorsurfaceitisplacedon.
518 mm
Quick mounting plate for vertical wall-mounted models
• Theidealsolutionfortightspaces:theappliance
ishookedontothissupport
• Quickerinstallationtime.
• Appliancecanbeeasilyxedinanglesorwhere
thereisnoaccesstotightenittothewall.
• Meetsloadbearingstandards.
Capacity manyplates
50to100litres 1
150to200litres 2
ECHELLE 1,000
Universal mounting bracket for vertical wall-mounted model
440 mm
660 mm
• Theidealsolutiontoreusesalltypesofold
waterheaterttingswithoutmakingextra
holes.
•Quickerinstallationtime
50lto300l:Ø20/27
500l: Ø26/34
