Service Icons
Name Icon Description
Stopped / Running
When the dryer is stopped the icon stands still. When
the dryer is running, the icon is rotating
Machine Control
Local Stop/Start
Remote Start/Stop
Network Control
Automatic restart after voltage failure
Automatic restart after voltage failure is active
Week Timer
Week Timer is active
Shutdown
Warning
Service
Service required
Icon
Description
Pressure
Temperature
Digital input
Special protection
Dryer
Fan
Frequency converter
Drain
Filter
Motor
Failure expansion module
Network problem
General alarm
3.4 Main Screen
