Atlas Copco LT2

Instruction book
12
52826D
14
15
13
3
2
4
10
16
5
6
7
8
9
Fig. 5.3 High-pressure side of LE10 60 Hz, LE15, -20, LF10, LT20, LT20-30
1 Bolt
2 Joint
3 O-ring
4 Spring
5 Outlet valve guard
6 Outlet valve disc
7 Valve seat
8 Inlet valve disc
9 Guide pin
10 Joint
11 Cylinder
12 Cylinder cover
13 Cylinder head
14 Joint
15 Outlet cap
16 Joint
Figs. 5.1 up to 5.3 Cylinder heads
2920 1585 00 - 54 -
