TECHNICAL SPECIFICATIONS
READINGS ON GAUGES
Gauge Reading Unit
Ammeter L1 (P1) Below max. rating A
Ammeter L2 (P2) Below max. rating A
Ammeter L3 (P3) Below max. rating A
Voltmeter (P4) Depends upon selector switch V
Frequencymeter (P5) Between 52.5 and 50 Hz
Hourmeter (P6) Adding up h
Fuel level (P7) Above 0 Fuel tank full
Engine temperature (P8) Below 105 °C
Engine oil pressure (P9) Below max. rating bar
Battery voltage gauge (P10) Below max. rating V
SETTINGS OF SWITCHES
Switch Function Activates at
Engine oil pressure Shut-down 0.5 bar
Engine coolant temperature Shut-down 105 °C
SPECIFICATIONS OF THE ENGINE/ALTERNATOR/UNIT
Reference
Absolute air inlet pressure 1 bar
values
Air inlet temperature 25 °C
Relative air humidity 30 %
Generator load Continuous
Limitations
Maximum ambient temperature 35 °C
without
Maximum altitude 1000 m
derating
Maximum relative air humidity 85 %
Minimum starting temperature -18 °C
Engine
Type PERKINS 1006 - TG2
Rated net output 91.5 kW
Load speed 1500 rpm
Electrical system 24 V
Battery (2x) 12 V / 66 Ah
Oil circuit capacity 16 l
Cooling circuit capacity 28 l
Fuel tank capacity 310 l
Fuse F4 10 A
Fuel consumption at full load/no load 22.8/3.7 l/h
Maximum run time with fuel tank 13 h
Alternator
Type ECN 34 LC–4
Rated net output 120 kVA
Voltage line-to-neutral 230 V
Voltage line-to-line 400 V
Frequency 50 Hz
Speed 1500 rpm
Power factor 0.8
Number of phases 3 + neutral
Winding connections Star
Insulation armature winding, class H
Insulation field winding, class H
Sensitivity of earth leak detector 0.03 - 0.3 - 1 A
Setting of Q1 145 A
Fuses F1, F2 and F3 for voltmeter selector switch 4 A
Maximum diffusion resistance of earthing rod 1 kΩ
Unit
Dimensions (LxWxH) 3112x1131x1507 mm
Weight net mass 1993 kg
Weight wet mass 2273 kg
SPECIFICATIONS OF THE OPTIONS
Specifications of the sockets option
Setting of circuit breaker Q2-3 63 A
Setting of circuit breaker Q4 32 A
Setting of circuit breaker Q5 16 A
Setting of circuit breaker Q6 16 A/30mA
Specifications of the dual frequency option
Reading on frequencymeter (P5) at 50 Hz 50 Hz
Reading on frequencymeter (P5) at 60 Hz 60 Hz
Rated net output at 50 Hz 100 kVA
Rated net output at 60 Hz 124 kVA
Load speed (50 Hz) 1500 rpm
Load speed (60 Hz) 1800 rpm
Fuel consumption at 50 Hz, full load/no load 22.8/3.7 l/h
Fuel consumption at 60 Hz, full load/no load 27.8/5.0 l/h
Maximum runtime with fueltank (50 Hz) 13 h
Maximum runtime with fueltank (60 Hz) 11 h
Frequency tolerance 0.25 %
Specifications of the single frequency option
Reading on frequencymeter (P5) 50 Hz
Load speed (50 Hz) 1500 rpm
Frequency tolerance 0.25 %
Specifications of the dual voltage option
Reading on voltmeter (P4) 230 V / 400 V
Specifications of the high current option
Reading on voltmeter (P4) 230 V / 400 V
23
INSTRUCTION MANUAL
