Exploded views/tables
Housing RRD 37
10
11
12
15
14
13
7
6
5
9
21
22
20
1
8
3
4
2
22
23
24
23
= Included in Service Kit
16
19
1817
5000330
OFF
15/16"
60 Nm
OFF
24mm
For North America only
45 ft.lb.
LOCTITE 641
Remark / Included in Service kitDescriptionQtyOrdering No.Ref. No.
Housing, compl.13510 0300 811(2-22)
Housing1-2
Trigger13510 0310 003
FRP 6x22Pin10108 1325 004
Valve liner13510 0396 005
11.1x1.6 / Service kit 4081 0179 90O-ring1-6
Valve pin13510 0395 007
Valve sleeve13510 0398 008
17.1x1.6 / Service kit 4081 0179 90O-ring1-9
Valve, compl.13510 0393 8010
Spring13510 0397 0011
Support washer13510 0399 0012
Plug13510 0309 0013
17.3x2.4 / Service kit 4081 0179 90O-ring1-14
10x2 / Service kit 4081 0179 90O-ring1-15
For North America onlyNipple, compl.13510 0591 8016(17-19)
1/2”. For North America onlyNipple1-17
For North America onlyStrainer14110 1397 0018
19.1x1.6. For North America only / Service kit 4081 0179 90O-ring1-19
Adapter13510 0251 0020
12.5 mmNipple13510 0250 0021
Service kit 4081 0179 90Seal-22
34x4 / Service kit 4081 0179 90O-ring1-23
51
Atlas Copco Tools - 9836 1761 00
Spare part listRRD37/57
