Remark / Included in Service kitDescriptionQtyOrdering No.Ref. No.
34.2x3 / Service kit 4081 0179 90O-ring1-24
Plate25
Screw26
Housing — RRD 57
10
11
12
15
14
13
7
6
5
9
21
22
20
1
8
3
4
2
22
23
24
23
= Included in Service Kit
16
19
1817
5000331
OFF
15/16"
60 Nm
OFF
24mm
For North America only
45 ft.lb.
LOCTITE 641
Remark / Included in Service kitDescriptionQtyOrdering No.Ref. No.
Housing, compl.13510 0340 811(2-22)
Housing1-2
Trigger13510 0310 003
FRP 6x22Pin10108 1325 004
Valve liner13510 0396 005
11.1x1.6 / Service kit 4081 0179 90O-ring1-6
Valve pin13510 0395 007
Valve sleeve13510 0398 008
17.1x1.6 / Service kit 4081 0179 90O-ring1-9
Valve, compl.13510 0393 8010
Spring13510 0397 0011
Support washer13510 0399 0012
Plug13510 0309 0013
17.3x2.4 / Service kit 4081 0179 90O-ring1-14
10x2 / Service kit 4081 0179 90O-ring1-15
For North America onlyNipple, compl.13510 0591 8016(17-19)
1/2”. For North America onlyNipple1-17
Atlas Copco Tools - 9836 1761 00
52
RRD37/57Spare part list
