Remark / Included in Service kitDescriptionQtyOrdering No.Ref. No.
For North America onlyStrainer14110 1397 0018
19.1x1.6. For North America only / Service kit 4081 0179 90O-ring1-19
Adapter13510 0251 0020
12.5 mmNipple13510 0250 0021
Service kit 4081 0179 90Seal-22
34x4 / Service kit 4081 0179 90O-ring1-23
34.2x3 / Service kit 4081 0179 90O-ring1-24
Plate25
Screw26
Percussive mechanism — RRD 37-11
Remark / Included in Service kitDescriptionQtyOrdering No.Ref. No.
Cylinder13510 0303 0022
Piston13510 0377 0023
Washer13510 0390 0024
Chisel sleeve13510 0384 0025
27x4 / Service kit 4081 0179 90O-ring1-26
Seal ring13510 0389 0027
Chisel sleeve ring13510 0388 0028
Service kit 4081 0179 90Buffer1-29
Front housing, compl.13510 0301 8030(31-37)
Housing1-31
Screw13510 0321 0032
Chisel retainer13510 0302 0133
FRP 3x24Pin10108 1198 0034
Service kit 4081 0179 90Spring1-35
FRP 3x12Pin10108 1192 0036
S6x30Pin13510 0402 0037
Key13095 0061 0052
53
Atlas Copco Tools - 9836 1761 00
Spare part listRRD37/57
