Percussive mechanism — RRD 37-12
Remark / Included in Service kitDescriptionQtyOrdering No.Ref. No.
Cylinder13510 0303 0022
Piston13510 0377 0023
Washer13510 0390 0024
Chisel sleeve13510 0384 0025
27x4 / Service kit 4081 0179 90O-ring1-26
Seal ring13510 0389 0027
Chisel sleeve ring13510 0388 0028
Service kit 4081 0179 90Buffer1-29
Front housing, compl.13510 0325 8030(31-37)
Housing1-31
Screw13510 0321 0032
Chisel retainer13510 0302 0133
FRP 3x24Pin10108 1198 0034
Service kit 4081 0179 90Spring1-35
FRP 3x12Pin10108 1192 0036
S6x30Pin13510 0402 0037
Key13095 0061 0052
Atlas Copco Tools - 9836 1761 00
54
RRD37/57Spare part list
