STbench EN System description
© Atlas Copco Industrial Technique AB - 9839 0879 01
13
System description
General functionality
Technical specifications
Item Description
Torque range (Hydraulic
Brakes)
Small frame: 0.2 N·m ÷ 500 N·m
Large frame: 0.2 N·m ÷ 1000 N·m
Torque range (Static Torque
Transducers)
Small frame: 0.5 N·m ÷ 250 N·m
Large frame: 0.5 N·m ÷ 2000 N·m
Torque range (Motorized Cell) Large frame: 4 N·m ÷ 400 N·m
Torque measurement accuracy
(Hydraulic Brakes and Torque
Transducers)
0.5 % readout ± 1 digit (from 20 % to 100 % of cell capacity)
1 % readout ± 1 digit (from 10 % to 20 % of cell capacity)
Torque measurement accuracy
(Motorized Cell)
0.5 % readout ± 1 digit (from 5 % to 100 % of cell capacity)
1 % readout ± 1 digit (from 1 % to 5 % of cell capacity)
Torque overload capacity 120 %
Angle measurement accuracy ± 1° over 360°
Joint simulation range 30° ÷ 1440°
Minimum speed to start a test Power tools: 4 rpm for at least 0.5 seconds
Click wrenches, pulse tools, peak tools: 2 rpm for at least 0.5 seconds
Maximum speed for hard joint
simulation (30°)
The brake cannot exceed a maximum speed (1000 rpm) to get the correct
hard joint simulation. Usually the tool speed in free rotation is higher than the
tool speed tested on the brake. In spite of this, the relation between the tool
speed in free rotation and the tool speed tested on the brake is strongly de-
pending on the tool itself.
Temperature stability of torque
measurement
0.1 % of capacity/10 °C
Battery power supply 2 batteries (12 V, 72 A/h)
Power supply 100-230 V~ ± 10 %, 50-60 Hz
AC power consumption 2300 W
Overvoltage category II
Sound pressure level < 80 dB(A)
AC fuses 1 fuse 10 A 500 VAC type gG
2 fuses 10 A 500 VAC type gG (in AC power socket)
2 fuses 6.3 A 500 V type gG (for tilting top plate)
Battery fuses 2 fuses 25 A 500 VAC type gG
Dimensions (L × W × H) Small frame: 1180 mm × 545 mm × 1500 mm
Large frame: 1403 mm x 528 mm x 1550 mm
Weight Small frame: 280 kg
Large frame: 390 kg
Oil for hydraulic circuitry 4 liters of Shell Tellus Oil T46 (refer to MSDS provided with the bench) - non-
flammable oil
Environmental
Environmental Class II
Pollution degree 2
Ambient temperature 5 °C ÷ 40 °C
Humidity 95 %, non-condensing
