Atlas Copco XAS 47 DD

59
Instruction Manual
1) At reference conditions, if applicable, and at normal shaft speed,
unless otherwise stated.
2) Data Measured according to Tolerance
Free air delivery ISO 1217 ed.3 +/- 5% 25 l/s <FAD<250 l/s
1996 annex D +/- 4% 250 l/s <FAD
The international standard ISO 1217 corresponds to following national standards:
- British BSI 1571 part 1 - German DIN 1945 Part 1
- Swedish SS-ISO 1217 - American ANSI PTC9
3) Air required for engine and compressor cooling, combustion and for compression.
4) with filter change
5) Coldstart: compressor oil DTE22 instead of DTE25
6) For Hose Reel application: maximum ambient temperature 30°C
Compressor type
XAHS 37 DD -
XAHS 70 DD7
XAS 47 DD -
XAS 90 DD7
XAS 47 DDG -
XAS 90 DD7G
XAS 57 DD -
XAS 110 DD7
DDG IT
Designation Unit Value Value Value Value
Design data
Compressor
1. Number of compression stages 1 1 11
Engine
1. Make Deutz Deutz Deutz Deutz
2. Type D2011L02 D2011L02 D2011L02 D2011L02
3. Coolant Oil Oil Oil Oil
4. Number of cylinders 2 2 2 2
5. Bore
mm 94 94 94 94
6. Stroke
mm 112 112 112 112
7. Swept volume
l 1.554 1.554 1.554 1.554
8. Output according to ISO 9249 G at
normal shaft speed
kW 21.6 21.6 23.3 23.3
- Load factor
% 50 50 50 50
9. Capacity of oil sump:
- Initial fill
l 8888
- Refill (max.)
4)
l 6.5 6.5 6.5 6.5
10.
Capacity of cooling system l ----
Unit
1. Capacity of compressor oil system l 8888
2. Net capacity of air receiver
l 16.7 16.7 16.7 16.7
3. Capacity of fuel tank
l 40 40 40 40
4. Air volume at inlet grating (approx.)
3)
m
3
/s 0.74 0.74 0.81 0.81
