DESIGN DATA
Compressor
Engine Unit
Alternator
Number of compression stages: 1
Designation Unit XAS 98 Kd XAS 98G Kd
Make Kubota Kubota
Type V1505-T V1505-T
Coolant oil oil
Number of cylinders 4 4
Bore mm 78 78
in 3.07 3.07
Stroke mm 78.4 78.4
in 3.09 3.09
Swept volume l 1.498 1.498
cu in 91.4 91.4
Output according to ISO 9249 G at
normal shaft speed
kW 33 33
BHP 44 44
- Load factor % 100 100
Capacity of oil sump:
- Initial fill l 5.5 5.5
US gal 1.5 1.5
- Refill (max.) l 5.35 5.35
US gal 1.4 1.4
Capacity of cooling system l 7.2 7.2
US gal 1.9 1.9
Designation Unit All Unit
Air volume at inlet grating (approx.) m
3
/s 0.93
cuft/s 32.8
Capacity of compressor oil system l 9
US gal 2.37
Capacity of standard fuel tanks l 60
US gal 16
Net capacity of air receiver l 16
US gal 4.2
Designation Unit XAS 98G Kd
Voltage AC V 230/400
Rated output kVA 9
Model T20FS
Protection Earth fault relay IT relay
Sockets 2x 400V/3ph/16A
1x 230V/1ph/16A
Protection rating IP 23
Standard IEC 34-1
