Atlas Copco ZS 4 VSD

Reference Name
11 CAUTION: capacitive voltage above 50 V may remain for 5 min after power
disconnection
12 Disconnect from the electrical supply before opening
Pictographs on control panel
Refer to the chapter Controller panel for pictographs of the Elektronikon controller.
Torque instruction
Please refer to the label in the electrical cabinet for the torque values of the electrical
connections.
Instruction book
56 AIF999999
