Rear Panel
10. Multi Function DIP Switch Inputs 2 & 3
Understanding the functionality of the DIP switches is key to maximizing the versatility of the AAPHD Series. When a switch is in the
up position, the function is “OFF or assigned to the feature stated”; when a switch is in the down position, the function is “ON or
assigned to the feature stated “.
Switch A
• DP SW #1 - Input 1 Phantom Power 24VDC is active when Input 2 or 3 is set to Mic mode and the switch is in the ON
position. Note: Only use this feature if you are using condenser microphones, otherwise leave in the “OFF” position.
• DP SW #2 - Mute Receive Inputs 2 & 3 - When “ON”, Input 2 or 3 signal will be muted if a signal is present on Input 1 or if
the Remote Mute Terminals are shorted together.
• DP SW #3 - Zone 2 Assign Inputs 2 & 3 - When “ON”, Input 2 or 3 signal will be routed to the Zone 2 Output terminals. The
signal routed is PRE the front panel level controls.
• DP SW #4 - When in the “MIC” position, Input 2 or 3 will accept microphone level signals; when in the “Line” position, Input 1
will accept line level or telephone signals.
11. Input 4
Input 4 can accept more than one type of audio signal. This input section has a 3 position Phoenix connector for Mic or Line input
signals and a 3.5mm stereo jack that is summed. The level to the amplifier mix is controlled by Input 4 level located on the front panel.
Note: Only one type of input signal can be applied at one time.
A. Balanced Mic / Line - Balanced Microphone or Line level signals connect to the (+), (–), and (G) terminals. To select between
Mic or Line input levels, refer to the DIP switch chart on the rear of the amplifier for feature assignment. If connecting an
unbalanced line level input, tie (short) the (G) and (–) terminals together for negative or ground connection and the positive or
(+) signal to the (+) terminal on the amplifier input. If the input is used in Mic mode, Phantom power for condenser type
microphones is available in the DIP switch settings on the rear panel.
B. Input 4 Stereo Summed - Input 4 consists of stereo 3.5mm summing inputs, suitable for connection to the output of iPod
®
,
CD/DVD players, etc.
12. Mic Trim
This variable control allows fine tuning of the gain of input. There is 20dB of variable gain available. The trim only applies when the input
is set to the “Mic” position on the DIP switch.
Signal Peak
5
5
64
3
2
1 9
0 10
8
7
Limit Power PHD
6
5
64
3
2
1 9
0 10
8
7
Master Level
5
64
3
2
1 9
0 10
8
7
3
5
64
3
2
1 9
0 10
8
7
4
5
64
3
2
1 9
0 10
8
7
2
5
64
3
2
1 9
0 10
8
7
1
5
64
3
2
1 9
0 10
8
7
AA200PHD
Professional Mixer Amplifier
120V AC 60Hz 500W
CLASS 2 WIRING
COM 4Ω 25V 70V
Pre Out
TrebleBass
Zone 2 - Output
Amplifier Output
Chan 5Chan 6
Sum InSum In
G
–
RMT
Mute
+
– +
600Ω
G
–
Channel 4 - Input Channel 3 - Input Channel 2 - Input
Channel 1 - Input
+
Mic
Trim
L + R Sum
G
–
+
Mic
Trim
Level VOX
Sens
Mic
Trim
G
–
+
Mic
Trim
1
Input 6
Off
On
2
Input 5
Off
On
3
Remote
Level
Master
Input 4,5,6
Mute RCV
RIS
4
On
Off
1
Phantom
Off
On
2
Mute RCV
Off
On
3
Zone 2
Off
On
4
Bal Input
Line
Mic
Power
Amp In
–
+
Return
Remote Level
Inputs
24,5,6
10V 6 5 4 GNDG
Remote Input
Select (RIS)
RIS
NC
PA Amplifier
Model AA200PHD
Output Rated 200W
Designed and Engineered
by Atlas Sound
Made in China
