Owner’s Manual
AA50PHD-CE
50W Mixer Amplifier
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
AA50PHD-CE Specifications
Type Mixer Amplifier
RoHS Compliant Yes
Safety Listings CE Compliant
Electrical Specifications
Power Output Max. Average Power @ 80Hz-15kHz with 1% THD, 4Ω 50W RMS
Transformer Outputs 50V 50W RMS
100V 50W RMS
4Ω 50W RMS
Front Panel
Power Switch Push Type
Indicators Signal, Limiter, Fault, Power
PHD Test Circuit Push Momentary for 100V Distributed Systems
Level Controls Master, Inputs 1 - 3
Rear Panel
Inputs Mic / Line Balanced Qty 1, 3 Position PHX Type. 3.5mm Pitch
Auxiliary Unbalanced Qty 2, RCA
Auxiliary Unbalanced Qty 1, 3.5mm
Amp In: Unbalanced RCA 600Ω
Tone Controls Bass ±6dB @ 100Hz
Treble ±6dB @ 10kHz
Mute VOX Sensitivity: Pot Rotary, Range 500uV - 200mV
Remote Mute: Contact Closure, 2 Position Phoenix, 3.5mm Pitch
Remote Level
Type 10V DCV Return
Connector 4 Position Phoenix 3.5mm pitch
Control Port Input 2, 3, 4 or Master
Supply Port 10VDC Send
Ground Port Ground
Remote Input Select (RIS)
Type Ground Activated
Connector 4 Position Phoenix 3.5mm pitch
Inputs Controlled 2, 3, 4
Control Switch Functions
Zone 2 Assign Inputs 1, 2, 3, 4
Mute Receive Inputs 2, 3, 4
Phantom Power Input 1
Mic line Select Input 1
